| Engine | |
|---|---|
| Horsepower (HP) | 28 HP |
| Engine Capacity (cc) | NA |
| Engine RPM | 2800 RPM |
| Cylinder | 3 |
| Air Filter | Dry type, Dual element |
| Cooling Type | Coolant Cooled |
| Transmission | |
|---|---|
| Clutch Type | Single Friction Plate |
| Transmission Type | Sync Reverser / Collarshift |
|---|
| Forward Speed | 1.6 – 19.5 kmph |
|---|
| Reverse Speed | 1.7 – 20.3 kmph |
|---|
| Forward Gears | 8 |
|---|
| Reverse Gears | 8 |
|---|
| Brakes | |
|---|---|
| Brake Type | Oil Immersed |
| Turning Radius (Brake) | 2300 mm |
| Steering | |
|---|---|
| Steering Type | Power Steering |
| Steering Adjustment | NO |
| PTO Power | |
|---|---|
| PTO Type | 6 Spline |
| PTO RPM | 540, 540E |
| PTO Power (HP) | 24 HP |
| Fuel Tank | |
|---|---|
| Fuel Tank Capacity (L) | 32 liters |
| Dimension & Weight | |
|---|---|
| Weight | 1070 kg |
| Wheelbase | 1574 mm |
| Overall Length | 2520 mm |
| Hydraulics | |
|---|---|
| Lift Capacity | 910 kg |
| Tyre Size | |
|---|---|
| Front Tyres | 6 X 14 |
| Rear Tyres | 8.3 X 24 / 9.5 X 24 |
| Drive & Warranty | |
|---|---|
| Drive Type | 4WD |
| Warranty | 5000 Hours / 5 year |
