| Engine | |
|---|---|
| Horsepower (HP) | 24 HP |
| Engine Capacity (cc) | NA |
| Engine RPM | 1800 RPM |
| Cylinder | 2 |
| Air Filter | Dry type, Dual element with dust unloader |
| Cooling Type | Water Cooled |
| Transmission | |
|---|---|
| Clutch Type | Single Friction plate |
| Transmission Type | Combi constant and sliding mesh |
|---|
| Forward Speed | 2.2 – 23.3 kmph |
|---|
| Reverse Speed | 2.2 – 8.7 kmph |
|---|
| Forward Gears | 6 |
|---|
| Reverse Gears | 2 |
|---|
| Brakes | |
|---|---|
| Brake Type | Oil Immersed |
| Turning Radius (Brake) | NA |
| Steering | |
|---|---|
| Steering Type | Power Steering |
| Steering Adjustment | NO |
| PTO Power | |
|---|---|
| PTO Type | 6 Spline |
| PTO RPM | 540 |
| PTO Power (HP) | 20 HP |
| Fuel Tank | |
|---|---|
| Fuel Tank Capacity (L) | 25 liters |
| Dimension & Weight | |
|---|---|
| Weight | 1440 kg |
| Wheelbase | 1550 mm |
| Overall Length | 2900 mm |
| Hydraulics | |
|---|---|
| Lift Capacity | 1000 kg |
| Tyre Size | |
|---|---|
| Front Tyres | 5 X 15 |
| Rear Tyres | 9.5 x 24 |
| Drive & Warranty | |
|---|---|
| Drive Type | 2WD |
| Warranty | 2000 Hours / 2 year |
