| Engine | |
|---|---|
| Horsepower (HP) | 39 HP |
| Engine Capacity (cc) | 2048 cc |
| Engine RPM | 2100 RPM |
| Cylinder | 3 |
| Air Filter | Pre-cleaner with 3 stage oil bath |
| Cooling Type | Water Cooled |
| Transmission | |
|---|---|
| Clutch Type | Single Clutch Heavy Duty Diaphragm |
| Transmission Type | Partial constant mesh |
|---|
| Forward Speed | 2.94-31.17 kmph |
|---|
| Reverse Speed | 4.46 kmph |
|---|
| Forward Gears | 8 |
|---|
| Reverse Gears | 2 |
|---|
| Brakes | |
|---|---|
| Brake Type | Dry / Oil Immersed |
| Turning Radius (Brake) | 3260 mm |
| Steering | |
|---|---|
| Steering Type | Mechanical / Power Steering |
| Steering Adjustment | NO |
| PTO Power | |
|---|---|
| PTO Type | 6 Spline |
| PTO RPM | 540 |
| PTO Power (HP) | 32 HP |
| Fuel Tank | |
|---|---|
| Fuel Tank Capacity (L) | 47 liters |
| Dimension & Weight | |
|---|---|
| Weight | 1840 kg |
| Wheelbase | 1880 mm |
| Overall Length | 3450 mm |
| Hydraulics | |
|---|---|
| Lift Capacity | 1200 kg |
| Tyre Size | |
|---|---|
| Front Tyres | 6 X 16 |
| Rear Tyres | 12.4 X 28 / 13.6 X 28 |
| Drive & Warranty | |
|---|---|
| Drive Type | 2WD |
| Warranty | 2000 Hours / 2 year |
