| Engine | |
|---|---|
| Horsepower (HP) | 75 HP |
| Engine Capacity (cc) | 3600 cc |
| Engine RPM | 2500 RPM |
| Cylinder | 4 |
| Air Filter | Dry type |
| Cooling Type | Coolant Cooled |
| Transmission | |
|---|---|
| Clutch Type | Double Clutch with Independent Clutch Lever |
| Transmission Type | Fully Constant mesh / Partial Synchro mesh* |
|---|
| Forward Speed | 2.16 – 32.07 kmph |
|---|
| Reverse Speed | 3.06 – 16.32 kmph |
|---|
| Forward Gears | 12 |
|---|
| Reverse Gears | 3 |
|---|
| Brakes | |
|---|---|
| Brake Type | Mechanically Actuated Oil Immersed Multi Disc Brakes |
| Turning Radius (Brake) | NA |
| Steering | |
|---|---|
| Steering Type | Power Steering |
| Steering Adjustment | NO |
| PTO Power | |
|---|---|
| PTO Type | 6 Spline |
| PTO RPM | 540, Reverse, Ground Speed |
| PTO Power (HP) | 59 HP |
| Fuel Tank | |
|---|---|
| Fuel Tank Capacity (L) | 60 litres |
| Dimension & Weight | |
|---|---|
| Weight | 2270 kg |
| Wheelbase | 2200 mm |
| Overall Length | NA |
| Hydraulics | |
|---|---|
| Lift Capacity | 1700 / 2000 kg |
| Tyre Size | |
|---|---|
| Front Tyres | 7.5 X 16 / 12.4 X 24 |
| Rear Tyres | 16.9 X 30 / 18.4 X 30 |
| Drive & Warranty | |
|---|---|
| Drive Type | 4WD |
| Warranty | 6000 Hours / 6 year |
