| Engine | |
|---|---|
| Horsepower (HP) | 90 HP |
| Engine Capacity (cc) | 2900 cc |
| Engine RPM | 2200 RPM |
| Cylinder | 4 |
| Air Filter | Dry AIr Cleaner |
| Cooling Type | Intercooler |
| Transmission | |
|---|---|
| Clutch Type | Double Clutch- Dry Friction Plate Wet Hydraulic Friction Plates Clutch |
| Transmission Type | Full Synchromesh |
|---|
| Forward Speed | 1.65 – 34.5 kmph |
|---|
| Reverse Speed | 1.65 – 34.5 kmph |
|---|
| Forward Gears | 12 |
|---|
| Reverse Gears | 12 |
|---|
| Brakes | |
|---|---|
| Brake Type | Mechanicallly Actuated Oil Immersed Multi Disc Brake- Standard Hydraulically Actuated Oil Immersed Multi Disc Brake- Optional |
| Turning Radius (Brake) | NA |
| Steering | |
|---|---|
| Steering Type | Power Steering |
| Steering Adjustment | YES |
| PTO Power | |
|---|---|
| PTO Type | 6 Spline |
| PTO RPM | 540, 540E, 1000, Reverse, Ground Speed(Optional) |
| PTO Power (HP) | 77 HP |
| Fuel Tank | |
|---|---|
| Fuel Tank Capacity (L) | 90 liters |
| Dimension & Weight | |
|---|---|
| Weight | 3250 kg |
| Wheelbase | 2259 mm |
| Overall Length | NA |
| Hydraulics | |
|---|---|
| Lift Capacity | 2500 kg |
| Tyre Size | |
|---|---|
| Front Tyres | 7.50 x 16, 6.50 x 20 & 10.0 x 16* (2WD) & 12.4 x 24 & 13.6 x 24* (4WD) |
| Rear Tyres | 18.4 X 30 |
| Drive & Warranty | |
|---|---|
| Drive Type | 2WD / 4WD |
| Warranty | 6000 Hours / 6 year |
