| Engine | |
|---|---|
| Horsepower (HP) | 44 HP |
| Engine Capacity (cc) | 3136 cc |
| Engine RPM | 2000 RPM |
| Cylinder | 3 |
| Air Filter | 3 Stage oil bath type |
| Cooling Type | Water Cooled, Oil cooler for engin oil |
| Transmission | |
|---|---|
| Clutch Type | Single dry disc friction plate – 305 Dia / Dual |
| Transmission Type | Combination of Constant and sliding mesh |
|---|
| Forward Speed | 3.1 – 29.2 kmph |
|---|
| Reverse Speed | 4.3 – 14.3 kmph |
|---|
| Forward Gears | 8 |
|---|
| Reverse Gears | 2 |
|---|
| Brakes | |
|---|---|
| Brake Type | Dry / Oil Immersed |
| Turning Radius (Brake) | NA |
| Steering | |
|---|---|
| Steering Type | Power / Mechanical Steering |
| Steering Adjustment | NO |
| PTO Power | |
|---|---|
| PTO Type | 6 Spline |
| PTO RPM | 540, 1000, Reverse |
| PTO Power (HP) | 37 HP |
| Fuel Tank | |
|---|---|
| Fuel Tank Capacity (L) | 48 liters |
| Dimension & Weight | |
|---|---|
| Weight | 1990 kg |
| Wheelbase | 1950 mm |
| Overall Length | 3440 mm |
| Hydraulics | |
|---|---|
| Lift Capacity | 1500 kg |
| Tyre Size | |
|---|---|
| Front Tyres | 6 X 16 / 7.5 X 16 / 9.5 X 20 / 8 X 18 |
| Rear Tyres | 13.6 X 28 / 14.9 X 28 |
| Drive & Warranty | |
|---|---|
| Drive Type | 2WD / 4WD |
| Warranty | 2000 Hours / 2 year |
