Price : ₹ 7,11,000 - ₹ 7,88,000
Engin Power : 55 HP PTO Power : 47 HP Gears : Forward Gears : 8 Reverse Gears : 2 Type of Steering : Mechanical / Power Steering Type of Brakes : Dry / Oil Immersed Lifting Capacity : 1800 kg
...
ENGINE Specification | |
---|---|
Horsepower (HP) | 55 HP |
Engine Capacity in cc | 3688 cc |
Engine RPM | 1850 RPM |
Cylinder | 3 |
Air Filter | Oil bath type |
Cooling Type | Water Cooled |
TRANSMISSION Specifications | |
---|---|
Clutch | Single / Dual |
Type of Transmission | Full Constant mesh |
Forward Speed | 2.7 - 30.7 kmph |
Reverse speed | 4.4 - 14.4 kmph |
No of Forward Gears | 8 |
No of Reverse Gears | 2 |
STEERING Specifications | |
---|---|
Type of Steering | Mechanical / Power Steering |
Steering Adjustment | NO |
PTO POWER Specifications | |
---|---|
Type of PTO | 6 Spline |
PTO RPM | 540, Reverse |
PTO POWER in HP | 47 HP |
FUEL TANK Specifications | |
---|---|
FUEL TANK Capacity(Liters) | 60 liters |
DIMENSION AND WEIGHT | |
---|---|
Weight | 2035 kg |
Wheelbase | 2220 mm |
Overall Length | 3600 mm |
HYDRAULICS Specifications | |
---|---|
Lifting capacity | 1800 kg |
TYRE SIZE Specifications | |
---|---|
Front Tyres | 6 X 16 / 6.5 X 16 / 7.5 X 16 |
Rear Tyres | 14.9 X 28 / 16.9 X 28 |
Drive Type | |
---|---|
Drive type | 2WD |
WARRANTY | |
---|---|
Warranty | 2000 hr/2 year |
