Kubota Neostar A211N

Kubota Neostar A211N image

Key Highlights

image LIFTING CAPACITY

750 kg

image ENGIN POWER

21 HP

image STEERING

Mechanical Steering

image CLUTCH

Single friction plate

image DRIVE TYPE

4WD

image ENGIN RPM

2100 RPM

image WEIGHT

600 kg

The Kubota Neostar A211N is a part of the A series and is the smallest model in the series. It has a 21 hp engine with a displacement of 999 cc.

Its power output is 16.2 kW. The PTO is independent, which means that it can be used while the engine is running. The PTO is disengaged when the engine is stopped. The transmission is hydrostatic with 3 ranges. The hydrostatic transmission is controlled by a lever on the right side of the steering wheel. The Kubota Neostar A211N has a 2-range hydrostatic transmission. The first range is for speeds up to 5 km/h and the second range is for speeds up to 15 km/h.

The hydrostatic transmission is engaged by a lever on the left side of the steering wheel. The Kubota Neostar A211N has a mid-mounted PTO with a power output of 16.2 kW. The mid-mounted PTO is engaged by a lever on the right side of the steering wheel. The Kubota Neostar A211N has aloader with a bucket capacity of 0.35 m3.

The loader is operated by a joystick on the right side of the steering wheel. The Kubota Neostar A211N has a 4-wheel drive. The 4-wheel drive is engaged by a lever on the right side of the steering wheel. The Kubota Neostar A211N has a turning radius of 2.8 m.

Kubota Neostar A211N Specifications

ENGINE
Horsepower (HP) 21 HP
Engine Capacity in cc 1001 cc
Engine RPM 2100 RPM
Cylinder 3
Air Filter Dry type
Cooling Type Liquid Cooled

Mini tractors

TRANSMISSION
Clutch Single friction plate
Type of Transmission Constant Mesh
Forward Speed 1.0 – 18.6 kmph
Reverse speed NA
No of Forward Gears 9
No of Reverse Gears 3

Filter Tractor By Company

BRAKES
Type of Brake Oil Immersed
Turning radius with brake 2100 mm

STEERING
Type of Steering Mechanical Steering
Steering Adjustment NO

More tractors by Kubota Tractors
PTO Power
Type of PTO 6 Spline
PTO RPM 540, 980
PTO POWER in HP 15 HP

FUEL TANK
FUEL TANK Capacity(Liters) 23 liters

DIMENSION AND WEIGHT
Weight 600 kg
Wheelbase 1560 mm
Overall Length 2390 mm

HYDRAULICS
Lifting capacity 750 kg

Popular tractors
TYRE SIZE
Front Tyres 5 X 12 / 7 X 12
Rear Tyress 8 X 18 / 8.3 X 20

Drive Type
Drive type 4WD

WARRANTY
Warranty 5 year
