| ENGINE | |
|---|---|
| Horsepower (HP) | 25 HP |
| Engine Capacity in cc | 1290 cc |
| Engine RPM | 2200 RPM |
| Cylinder | 2 |
| Air Filter | Wet type |
| Cooling Type | Water Cooled |
Mini tractors
| TRANSMISSION | |
|---|---|
| Clutch | Single Friction Plate |
| Type of Transmission | Synchromesh |
| Forward Speed | 2.25 - 20 kmph |
| Reverse speed | NA |
| No of Forward Gears | 8 |
| No of Reverse Gears | 2 |
| BRAKES | |
|---|---|
| Type of Brake | Dry Internal Exp. Shoe |
| Turning radius with brake | 2200 mm |
| STEERING | |
|---|---|
| Type of Steering | Power Steering / Mechanical Steering |
| Steering Adjustment | NO |
| PTO Power | |
|---|---|
| Type of PTO | 6 Spline |
| PTO RPM | 540 |
| PTO POWER in HP | 21 HP |
| FUEL TANK | |
|---|---|
| FUEL TANK Capacity(Liters) | NA |
| DIMENSION AND WEIGHT | |
|---|---|
| Weight | 890 kg |
| Wheelbase | 1550 mm |
| Overall Length | 2600 mm |
| HYDRAULICS | |
|---|---|
| Lifting capacity | 1000 kg |
| TYRE SIZE | |
|---|---|
| Front Tyres | 5 X 12 / 6 X 12 |
| Rear Tyress | 8 X 18 / 8.3 X 20 |
| Drive Type | |
|---|---|
| Drive type | 4WD |
| WARRANTY | |
|---|---|
| Warranty | NA |
