Price : ₹ 4,90,000 - ₹ 4,90,000
Engin Power : 25 HP PTO Power : 21 HP Gears : Forward Gears : 8 Reverse Gears : 2 Type of Steering : Power Steering / Mechanical Steering Type of Brakes : Dry Internal Exp. Shoe Lifting Capacity : 1000 kg
...
ENGINE Specification | |
---|---|
Horsepower (HP) | 25 HP |
Engine Capacity in cc | 1290 cc |
Engine RPM | 2200 RPM |
Cylinder | 2 |
Air Filter | Wet type |
Cooling Type | Water Cooled |
TRANSMISSION Specifications | |
---|---|
Clutch | Single Friction Plate |
Type of Transmission | Synchromesh |
Forward Speed | 2.25 - 20 kmph |
Reverse speed | NA |
No of Forward Gears | 8 |
No of Reverse Gears | 2 |
BRAKES Specifications | |
---|---|
Type of Brake | Dry Internal Exp. Shoe |
Turning radius with brake | 2200 mm |
STEERING Specifications | |
---|---|
Type of Steering | Power Steering / Mechanical Steering |
Steering Adjustment | NO |
PTO POWER Specifications | |
---|---|
Type of PTO | 6 Spline |
PTO RPM | 540 |
PTO POWER in HP | 21 HP |
FUEL TANK Specifications | |
---|---|
FUEL TANK Capacity(Liters) | NA |
DIMENSION AND WEIGHT | |
---|---|
Weight | 890 kg |
Wheelbase | 1550 mm |
Overall Length | 2600 mm |
HYDRAULICS Specifications | |
---|---|
Lifting capacity | 1000 kg |
TYRE SIZE Specifications | |
---|---|
Front Tyres | 5 X 12 / 6 X 12 |
Rear Tyres | 8 X 18 / 8.3 X 20 |
Drive Type | |
---|---|
Drive type | 4WD |
WARRANTY | |
---|---|
Warranty | NA |
