Price : ₹ 6,93,000 - ₹ 7,60,000
Engin Power : 55 HP PTO Power : 47 HP Gears : Forward Gears : 8 Reverse Gears : 4 Type of Steering : Power Steering Type of Brakes : Oil Immersed Lifting Capacity : 1600 kg
...
ENGINE Specification | |
---|---|
Horsepower (HP) | 55 HP |
Engine Capacity in cc | 3022 cc |
Engine RPM | 2400 RPM |
Cylinder | 3 |
Air Filter | Dry type, Dual element |
Cooling Type | Coolant Cooled with overflow reservoir |
TRANSMISSION Specifications | |
---|---|
Clutch | Single / Dual |
Type of Transmission | Collarshift |
Forward Speed | 3.18 – 33.48 kmph |
Reverse speed | 4.22 – 14.9 kmph |
No of Forward Gears | 8 |
No of Reverse Gears | 4 |
BRAKES Specifications | |
---|---|
Type of Brake | Oil Immersed |
Turning radius with brake | 2900 mm |
STEERING Specifications | |
---|---|
Type of Steering | Power Steering |
Steering Adjustment | NO |
PTO POWER Specifications | |
---|---|
Type of PTO | 6 Spline |
PTO RPM | 540, 540E |
PTO POWER in HP | 47 HP |
FUEL TANK Specifications | |
---|---|
FUEL TANK Capacity(Liters) | 60 liters |
DIMENSION AND WEIGHT | |
---|---|
Weight | 1920 kg |
Wheelbase | 1960 mm |
Overall Length | 3420 mm |
HYDRAULICS Specifications | |
---|---|
Lifting capacity | 1600 kg |
TYRE SIZE Specifications | |
---|---|
Front Tyres | 6.5 X 16 / 7.5 X 16 |
Rear Tyres | 14.9 X 28 / 16.9 X 28 |
Drive Type | |
---|---|
Drive type | 2WD |
WARRANTY | |
---|---|
Warranty | 5000 Hours / 5 year |
