Price : 11,15,000 - ₹ 12,00,000
Engin Power : 65 HP PTO Power : 55 HP Gears : Forward Gears : 15 Reverse Gears : 3 Type of Steering : Power Steering Type of Brakes : Oil Immersed Lifting Capacity : 2200 kg
...
ENGINE Specification | |
---|---|
Horsepower (HP) | 65 HP |
Engine Capacity in cc | NA |
Engine RPM | 2100 RPM |
Cylinder | 4 |
Air Filter | Dry type with clog indicator |
Cooling Type | Coolant Cooled |
TRANSMISSION Specifications | |
---|---|
Clutch | Dual Dry |
Type of Transmission | Synchromesh |
Forward Speed | 1.71 – 33.54 kmph |
Reverse speed | 1.63 - 32 kmph |
No of Forward Gears | 15 |
No of Reverse Gears | 3 |
STEERING Specifications | |
---|---|
Type of Steering | Power Steering |
Steering Adjustment | NO |
PTO POWER Specifications | |
---|---|
Type of PTO | 6 Spline |
PTO RPM | 540, 540E, Reverse |
PTO POWER in HP | 55 HP |
FUEL TANK Specifications | |
---|---|
FUEL TANK Capacity(Liters) | 60 liters |
DIMENSION AND WEIGHT | |
---|---|
Weight | NA |
Wheelbase | 2220 mm |
Overall Length | 3710 mm |
HYDRAULICS Specifications | |
---|---|
Lifting capacity | 2200 kg |
TYRE SIZE Specifications | |
---|---|
Front Tyres | 7.5 X 16 / 9.5 X 24 |
Rear Tyres | 16.9 X 28 |
Drive Type | |
---|---|
Drive type | 2WD / 4WD |
WARRANTY | |
---|---|
Warranty | 2000 Hours / 2 year |
