farmtrac-atom-26

Farmtrac Atom 26

Price : ₹ 4,80,000 - ₹ 4,80,000

Engin Power : 26 HP
PTO Power : 20 HP
Gears :
Forward Gears : 9
Reverse Gears : 3
Type of Steering : Balanced Power Steering
Type of Brakes : Multi Plate Oil Immersed Brakes
Lifting Capacity : 750 kg

...


Farmtrac Atom 26 Specifications

ENGINE Specification
Horsepower (HP) 26 HP
Engine Capacity in cc NA
Engine RPM 2700 RPM
Cylinder 3
Air Filter Dry type
Cooling Type Coolant Cooled

TRANSMISSION Specifications
Clutch Single Friction Plate
Type of Transmission Constant mesh
Forward Speed 1.5 - 22.5 kmph
Reverse speed 1.8 - 11.2 kmph
No of Forward Gears 9
No of Reverse Gears 3

More tractors by Farmtrac Tractors

BRAKES Specifications
Type of Brake Multi Plate Oil Immersed Brakes
Turning radius with brake 1900 mm

STEERING Specifications
Type of Steering Balanced Power Steering
Steering Adjustment NO

PTO POWER Specifications
Type of PTO 6 Spline
PTO RPM 540, 540E
PTO POWER in HP 20 HP

FUEL TANK Specifications
FUEL TANK Capacity(Liters) 24 liters

DIMENSION AND WEIGHT
Weight 900 kg
Wheelbase 1550 mm
Overall Length 2730 mm

HYDRAULICS Specifications
Lifting capacity 750 kg

TYRE SIZE Specifications
Front Tyres 6 X 12
Rear Tyres 8.3 X 20

Drive Type
Drive type 4WD

WARRANTY
Warranty 3000 hr /3 year
